Toyota GR010 Hybrid (2026 Evo)

TYRES

• Slick (Qualifying Soft compound), Front: 28.2 PSI, Rear: 27.8 PSI, tyre blanket temp: 90°C (front) / 85°C (rear). Optimal operating window for max grip: 95–105°C tread surface.

ELECTRONICS

• TC: 2, ABS: 3, Engine Braking: 4 (medium-low, aids rotation into Senna S and Mergulho), Brake Bias: adjustable in-cockpit, base 54.0% front, Hybrid Deploy: Max attack (full deploy every straight), Regen: 8 (aggressive, front-axle biased under braking for extra stability into heavy zones)

SUSPENSION

• // FRONT
• Ride Height: 28 mm
• Wheel Rate FL / FR: 210000 N/m / 210000 N/m
• ARB: 220 N/m
• Brake Torque Multiplier: 100%
• Brake Bias: 54.0%
• // REAR
• Ride Height: 32 mm
• Wheel Rate RL / RR: 195000 N/m / 195000 N/m
• ARB: 160 N/m
• Diff Preload: 55 Nm
• Diff Coast: 0.35
• Diff Power: 0.55

DAMPERS

AERO

• Front Downforce: Level 7 (high-medium), Rear Wing: Level 8, Overall Balance: rear-biased for Ferradura/Junção traction and Mergulho stability, Brake Ducts: Front 4 / Rear 3 (heavy braking track, manage temps into Senna S and Bico de Pato)

KEY SETUP NOTE

• Interlagos counter-clockwise loading reverses the usual outside-tyre stress pattern, so the right-side tyres (loaded through Senna S entry, Descida do Sol and Junção) take more thermal load than a clockwise track — front-right and rear-right pressures are trimmed slightly lower than left-side to compensate and keep the contact patch even for one qualifying lap.

TRACK GUIDE

• Senna S (T1/2): brake as late as possible in a straight line, release trail-brake progressively — the car must rotate on entry without unsettling the rear for the quick left-right; front aero and brake bias are critical here.
• Ferradura (T4): this is the most important traction zone on the lap — get the car rotated early and get on power progressively to maximize speed down the back straight; diff power lock and rear ARB softness help put power down cleanly.
• Bico de Pato (T9/10) & Mergulho (T11): ride the chicane kerbs aggressively but be ready for the compression at Mergulho — soft-ish fast bump damping absorbs the hit without unsettling the car for the tight Junção that follows.
• Junção (T12): the lap's second key traction zone — a clean, straight exit here feeds the entire final uphill sector; sacrifice a fraction of entry speed for a perfect exit line.
• Final climb to Arquibancadas (T14): power-limited uphill — carry maximum exit speed from Junção and use full hybrid deploy through this section into the final corner and onto the main straight, where the lap time is ultimately banked.
